| ID | Part number | Name |
| 1 | 10Y-11-00009 | Housing |
| 2 | 07000-15430 | O-ring |
| 3 | 01010-51235 | Bolt M12 x 35 |
| 4 | 01643-31232 | Washer 12 |
| 5 | 10Y-11-00011 | Seal housing |
| 6 | 07000-12135 | O-ring |
| 7 | 07012-00085 | Seal |
| 8 | GB276-6214 | Deep groove ball bearing |
| 9 | 10Y-11-05000 | Coupling |
| 10 | 10Y-11-00012 | Pressure plate |
| 11 | 10Y-11-00024 | O-ring |
| 12 | 01010-51225 | Bolt M12 x 25 |
| 13 | 10Y-11-00013 | Locking strip |
| 14 | 10Y-11-00010 | Gear shaft |
| 15 | 01010-51025 | Bolt M10 x 25 |
| 16 | 01602-21030 | Washer 10 |
| 17 | 10Y-11-00017 | Gear |
| 18 | 10Y-11-00016 | Intermediate shaft |
| 19 | GB276-6213 | Deep groove ball bearing |
| 20 | 04071-00120 | Retaining ring |
| 21 | 10Y-11-00015 | Pressure plate |
| 22 | 10Y-11-00023 | Cover |
| 23 | 01010-51030 | Bolt M10 x 30 |
| 24 | 10Y-11-00022 | Gear |
| 25 | GB276-6207 | Deep groove ball bearing |
| 26 | 04065-07225 | Retaining ring |
| 27 | 10Y-11-00019 | Cover |
| 28 | 07000-15185 | O-ring |
| 29 | 10Y-11-00020 | Gear |
| 30 | GB276-6210 | Deep groove ball bearing |
| 31 | 04065-09030 | Retaining ring |
| 32 | 07000-72095 | O-ring |
| 33 | 10Y-11-00021 | Cover plate |
| 34 | 01010-51020 | Bolt M10 x 20 |
| 35 | 01643-31032 | Washer 10 |
| 36 | 04530-11628 | Eye bolt |
